SGA8BX
RAF8 - NC.png
raf8.dwng.pngSGA8BX
8" Bx Round Adjustable High Output - 8000Lm
8" round open aperture deep regressed recessed high output LED adjustable accent for high ceiling illumination in malls, churches and commercial applications. LED module tilts 35°, rotates 360°. Two-stage optical system for smooth light distribution and focus control. Quick change LED module with interchangeable optics for job site adjustment and fixture maintenance. Tool-less driver and j-box access. Posi-lock trim retention torsion springs. May be used for slope ceiling application.
Resources
Families
- A Spec
Trim Type
- Adjustable
- Flange
Lumens
- 6000 Lm
- 7000 Lm
- 8000 Lm
Distribution
- Medium
- Narrow
- Very Wide
- Wide
Shape
- Round
Aperture
- 8 In.
Installation Type
- New Construction
Emergency Options
- Integral EM Battery
Dimming Protocol
- 0-10 V
- Bluetooth Wireless
- DALI
- DMX
- ELV
- Forward Phase
- MLV
Ratings & Compliance
- Buy American Act (BAA)
- Made in America
- Non-IC
Lamp Source
- LED
CCT
- 2700K
- 3000K
- 3500K
- 4000K
CRI
- 80 CRI
- 90 CRI
Watts
- 40 w
- 49 w
- 58 w
Listings
- CUL
- ETL
- UL
Warranty
- 5 yr
Voltage
- 120 V
- 277 V
- 347 V
Dimming Range
- 1%
- < 1%
- Non-Dimmable
