SS3DNMO, SS3DNMI, SS3DNMR

3" Xt Square Deep Downlight N-Line - 3000Lm

Spectrum’s A Spec 3" recessed square downlight series features a deep plenum housing and trim for general illumination. Precision Die-formed 20 gauge galvanized steel housing and integral junction box with (3) 5/8", (3) 7/8" and (2) 1 1/8" knockouts. Junction box capacity: 8 12AWG rated for 90 °C. Tool-less driver and junction box access for ease of maintenance. Posi-loc trim rentention springs for 5/8"-1" ceiling thickness. Use PR2 for up to 2" thick ceiling. For thicker ceilings consult factory.
Specification Sheet

Resources

Families

  • A Spec

Trim Type

  • Flangeless

Lumens

  • 1000 Lm
  • 1300 Lm
  • 2000 Lm
  • 3000 Lm

Distribution

  • Medium
  • Narrow
  • Very Narrow
  • Wide

Shape

  • Square

Aperture

  • 3 In.

Installation Type

  • New Construction
  • Retrofit & Remodel

Options & Accessories

  • Integral EM Battery

Dimming Protocol

  • 0-10 V
  • Bluetooth Wireless
  • DMX
  • ELV
  • Forward Phase
  • MLV

Ratings & Compliance

  • Buy American Act
  • IC
  • Made in America
  • Non-IC
  • Wet

Lamp Source

  • LED

CCT

  • 2700K
  • 3000K
  • 3500K
  • 4000K

CRI

  • 83 CRI
  • 98 CRI
